Open the Page

Access the Alarm Viewer page from the Diagnostics tab (System > Alarm Viewer):

Alarm Viewer page:
NOTE: This page is updated every 5 seconds.

Diagnostic Information

The Alarm Viewer page reports detected application errors. You can read, filter, and sort information about alarm objects on this page. Adjust the type of information displayed by the Alarm Viewer in the Filter Alarms box.

Each alarm has a timestamp, a description, and an acknowledgement status:

  • critical (red)

  • acknowledged (green)

  • information (blue) (These alarms do not require acknowledgement.)

This table describes the components of the page:

Column

Description

Type

This column describes the alarm type.

Status

STOP

You need to acknowledge the alarm.

ACK

An alarm has been acknowledged.

OK

An alarm does not require acknowledgment.

Message

This column contains the text of the alarm message.

Occurance

This column contains the date and time that the alarm occurred.

Acknowledged

This column reports the acknowledged status of the alarm.

Zone

This column contains the area or geographical zone from which the alarm comes (0: common area).
