Introduction
This page allows you to carry out diagnostics on the modules in the local rack configuration that includes the Ethernet module.
By clicking on a module in the configuration, you obtain a set of diagnostic information on this module:
NOTE: For further information, refer to the FactoryCast User Guide.
Accessing the Server Rack Display Page
Follow this procedure to access the rack display page from the index page:
Step
Action
1
Click the Diagnostics link.
2
Click the Rack Display link.
The TSX ETY4103 rack display page apears. An example is shown below:
