General
The Modbus protocol creates a hierarchical structure (one master and several slaves).
The master manages all exchanges according to two types of dialog:
the master exchanges with a slave and awaits the response
the master exchanges with all slaves without awaiting a response (broadcast queries).
Illustration
The following illustration shows a Modbus network:
