Ventilation module: mounting
(Original Document)
General
The ventilation modules associated with Premium/Atrium stations must be mounted on 35mm wide and 15mm deep mounting rails (type AM1-ED...) in order to compensate for the depth of the rack.
Diagram:
Mounting position
Mounting position for ventilation modules according to rack-type:
