Connecting an encoder with a TSX TAP S15 05 accessory
(Original Document)
About us
General
A specific cable, supplied by the manufacturer of the encoder, is used for connecting an encoder using an auxiliary TSX TAP S15 05.
Illustration
The pinout of TSX TAP S15 05 is as follows:
