Introducing the TSX ASY 800 module
(Original Document)
At a Glance
The TSX module ASY 800 is a module with 8 shared outputs. The following ranges are offered for each output:
Illustration
The following diagram shows the analog input module TSX ASY 800 :
NOTE: if the modules TSX ASY 800 are supplied by internal 24 V (TSX PSY •••), the number of modules is reduced to :
  • 1 per rack with simple format or standard supply,
  • 2 per rack with double format supply.
