Catalog of Analog Input Modules
|
|
|
(Original Document)
|
|
Catalog of Analog Input Modules
|
|
|
(Original Document)
|
|
Module type
|
Inputs
|
|||||
 |
 |
 |
 |
|||
|
Number of channels
|
16
|
8
|
4
|
16
|
4
|
|
|
Range
|
+/- 10 V
0..10 V
0..5 V
1..5 V
0..20 mA
4..20 mA
|
+/- 80 mV
Thermocouple
|
+/- 10 V
0..10 V
+/- 5 V
0..5 V
1..5 V
0..20 mA
4..20 mA
-13..+63 mV
0..400 Ohms
0..3850 Ohms
Thermowell
Thermocouple
|
|||
|
Current consumed at 24 VR
|
0 mA
|
|||||
|
Current consumed at 5 V
|
270 mA (typ.)
380 mA (max.)
|
475 mA (typ.)
630 mA (max.)
|
500 mA (typ.)
800 mA (max.)
|
300 mA (typ.)
400 mA (max.)
|
660 mA (typ.)
940 mA (max.)
|
|
|
Voltage shared channel mode
|
Shared
|
+/- 200 VDC
|
Shared
|
+/- 100 VDC
|
+/- 200 VDC
|
|
|
Resolution
|
12 bits
|
16 bits
|
||||
|
Connections
|
2 x Sub-D
25 pin
|
1 x Sub-D
25 pin
|
2 x Sub-D
25 pin
|
20 pin screw terminal block
|
||
|
Dedicated TELEFAST 2
|
ABE-7CPA 02
ABE-7CPA 03
|
ABE-7CPA 02
ABE-7CPA 03
|
ABE-7CPA 02
ABE-7CPA 31
|
ABE-7CPA 02
ABE-7CPA 03
ABE-7CPA 21
|
ABE-7CPA 12
|
-
|
|
TSX•• reference
|
AEY 1600
|
AEY 800
|
AEY 810
|
AEY 420
|
AEY 1614
|
AEY 414
|
