RJ45 to RJ45 RS485 Communication Cable

To support serial RS485 communications on the 171 CBU 78090, 171 CBU 98090, or 171 CBU 98091 processors, you can use the Schneider Electric TCSMCN3M3M3S2 RJ45 to RJ45 Modbus cable to connect to a remote Momentum device.

The TCSMCN3M3M3S2 cable has a length of 2 m and presents the following wiring profile:
