Setpoint programmers have their own debugging screen. When in Online mode, they have access to all available reconfiguration and data saving services.
NOTE: Any reconfiguration in Online mode immediately prevents the setpoint programmer from functioning.
The following diagram shows a setpoint programmer in Debugging mode.
Profile execution is displayed dynamically. The following information is provided:
-
Number of current segment (SEG_OUT),
-
Number of current iteration (CUR_ITER),
-
Execution time of the current segment (TIME_SEG),
-
Total time (TIME_TOTAL).
Notes on Operation:
-
The TIME_SEG and TIME_TOTAL times change even if the profile is frozen.
-
The state of monitoring outputs is directly displayed in the channel area.
-
You may control each profile directly from the Command button located in the tab.
-
When the profile is frozen, the SP (%MFr.m.c.20) setpoint values and STR0 to STR7 (%MWr.m.c.3.0 to %MWr.m.c.3.7) control outputs are not updated during execution of NEXT and BACK commands. They are refreshed as soon as profile unfreezes.
-
Neither the target setpoint value (SPi) nor the duration of the current segment may be modified.
